413-01-7 Instrument Cluster 413-01-7 DESCRIPTION AND OPERATION from the PJB will also carry a 'wake-up' message for the instrument cluster. Brake Warning Indicator The indicator is controlled by high speed CAN messages from the ABS module and the parking brake control module. If it illuminates when you are driving, check that the parking brake is not engaged. If the parking brake is not engaged, this indicates a malfunction. Have the system checked by a properly trained technician immediately. If a condition exists where the parking brake cannot be applied, the parking brake control module issues a CAN message to the instrument cluster which flashes the warning lamp on and off and is accompanied with a message 'CANNOT APPLY PARK BRAKE'. If a fault occurs in the parking brake system, the parking brake control module issues a CAN message to the instrument cluster which illuminates the warning indicator and displays the message 'PARK BRAKE FAULT' in the message center. Water-in-fuel indicator The water-in-fuel indicator lamp will come on if there is excess water in the fuel filter. Anti-lock Braking System (ABS) Warning Indicator The ABS warning indicator is controlled by the ABS module. If a fault in the ABS system is detected by the ABS module, the module issues a high speed CAN message to the instrument cluster to illuminate the ABS warning indicator and display the message 'ABS FAULT' in the instrument cluster. If it illuminates when you are driving, this indicates a malfunction. You will continue to have normal braking (without ABS). Have the system checked by a properly trained technician as soon as possible. Engine Malfunction Indicator Lamp (MIL) The MIL warning indicator is controlled by the ECM and illuminated by the instrument cluster on receipt of a message on the high speed CAN bus from the ECM. If either lamp illuminates when the engine is running, this indicates a fault. The engine will continue to run but it may have limited power. If it flashes when you are driving, reduce the speed of your vehicle immediately. If it continues to flash, avoid heavy acceleration or deceleration. If both lamps illuminate together, stop your vehicle as soon as it is safe to do so (continued use may cause reduced power and cause the engine to stop). Turn the ignition off and attempt to restart the engine. If the engine restarts have the system checked by a properly trained technician immediately. If the engine does not restart the vehicle must be checked before continuing your journey. Airbag Warning Indicator The airbag warning indicator is controlled by the instrument cluster. If it illuminates while driving, this indicates a malfunction. The indicator remains illuminated after the 3 second period has expired until the instrument cluster receives a turn off message on the high speed CAN bus from the RCM (restraints control module). Front Fog Lamp Indicator The green colored front fog lamp indicator is controlled by the PJB and illuminated by the instrument cluster on receipt of a front fog lamp on message on the medium speed CAN bus from the PJB. The front fog lamp indicator will come on when you switch the front fog lamps on. Stability control (ESP) warning lamp The ESP supports stability when the vehicle starts to slide away from your intended path. This is performed by braking individual wheels and reducing engine torque as needed. The system also provides an enhanced traction control function by reducing engine torque and braking if the wheels spin when you accelerate. This improves your ability to pull away on slippery roads or loose surfaces, and improves comfort by limiting wheel spin in hairpin bends. Emergency brake assist will detect when you brake heavily by measuring the rate at which you press the brake pedal. It will provide maximum braking efficiency as long as you press the pedal. Emergency brake assist can reduce stopping distances in critical situations.
