Eixo de saída

Manual Transmission/Transaxle – Vehicles With: 5-Speed 308-03A-37 308-03A-37 Manual Transmission - MT75 DISASSEMBLY AND ASSEMBLY OF SUBASSEMBLIES ‡ Locate the special tool in the recesses off the bearing ring. 308-191 ELE0011322 5. NOTE: Mark the position of the second gear wheel in relation to the synchronizer ring to aid installation. Remove the second gear wheel, the needle roller bearing and synchronizer ring. ELE0011322 6. NOTE: Mark the position of the shift ring in relation to the first gear wheel to aid installation.. Components are paired. NOTE: Remove the circlip. Remove the first/second gear synchronizer and the first gear wheel. 1. First/second gear synchronizer. 2. First gear wheel. 3. Needle roller bearing. 1 2 3 S1601195 7. NOTE: Mark the position of the shift ring in relation to the reverse gear wheel to aid installation. Components are paired. NOTE: Clamp the output shaft the other way round in the vise. NOTE: Remove the circlip. Remove the fifth/reverse gear synchronizer, the reverse gear wheel and needle roller bearing. 1. Fifth/reverse gear synchronizer. 2. Reverse gear wheel. 3. Needle roller bearing. 1 2 3 ELE0011333 Assembly 1. Carefully clean and check all sliding parts and lubricate the synchronizer rings with Manual transmission fluid before assembly. 2. Install the needle roller bearing, reverse gear wheel and synchronizer unit. 1. Install the reverse gear wheel. 2. Install the synchronizer.
