Eixo de saída

Manual Transmission/Transaxle – Vehicles With: 5-Speed 308-03A-38 308-03A-38 Manual Transmission - MT75 DISASSEMBLY AND ASSEMBLY OF SUBASSEMBLIES 3. Install the snap ring. 3 2 1 ELJ1601694 3. Install the first/second gear synchronizer unit. 1. Install the needle roller bearing. 2. Install the gear wheel. 3. Install the synchronizer unit. ‡ Install the circlip. 3 2 1 ELJ1601686 4. Install the synchronizer ring, needle roller bearing and second gear wheel. 1. Install the needle roller bearing. 2. Install the synchronizer ring. 3. Install the gear wheel. 3 2 1 ELJ1601684 5. NOTE: Slide the inner bearing ring onto the output shaft as far as the shoulder. NOTE: Install a new inner bearing ring and needle bearing. Using a hot air gun heat the inner bearing ring to approximately 100 ° C and install it. ELJ1601683 6. NOTE: Install the synchronizer with the small collar upwards. NOTE: Install the needle roller bearing. Install the third/fourth gear synchronizer. 1. Install the gear wheel. 2. Install the synchronizer. 3. Install the circlip. 3 2 1 ELJ1601682 7. Install the fifth gear wheel. 1. Install the needle roller bearing. 2. Install the synchronizer ring.
