Eixo de saída

Manual Transmission/Transaxle – Vehicles With: 5-Speed 308-03A-36 308-03A-36 Manual Transmission - MT75 DISASSEMBLY AND ASSEMBLY OF SUBASSEMBLIES Output Shaft Special Tool(s) Remover, Mainshaft Needle Bearing Sleeve 308 - 191 (16 - 056) 16056 General Equipment Hot air gun Materials Name Specification Manual transmission WSD - M2C200 - C fluid Disassembly 1. CAUTION: Mark the position of the synchronizer rings in relation to the synchronizer units to aid installation. Remove the input shaft and fourth gear synchronizer ring from the output shaft. ‡ Remove the output shaft locating bearing. ELE0010466 2. Remove the fifth gear wheel and synchronizer ring from the output shaft. 1. Remove the gear wheel. 2. Remove the gear synchronizer ring. 3. Remove the needle roller bearing. 1 2 3 JI601180 3. WARNING: Do not allow the synchronizers to fall apart. Failure to follow these instructions may result in personal injury. CAUTION: Use soft jaws for all operations in a vise. NOTE: Clamp the output shaft in a vise with the output end. Remove the third/fourth gear synchronizer unit together with the third gear wheel. 1. Remove the circlip. 2. Third/fourth gear synchronizer. 3. Needle roller bearing. 4. Third gear wheel. 1 2 4 3 ELE0011323 4. Using the special tool, remove the third gear bearing ring.
