Manual Transmission/Transaxle – Vehicles With: 5-Speed 308-03A-4 308-03A-4 Manual Transmission - MT75 DESCRIPTION AND OPERATION The MT - 75 manual transmission is a “ three - shaft transmission". MT - 75 means: œ M: Manual. œ T: Transmission œ 75: Distance between main shaft and counter shaft in mm. The aluminum transmission housing consists of two closed sections. The reinforcing ribs on the transmission housing have been revised to reduce noise and vibration. Mainshaft and Counter Shaft 3 2 1 ELE0010444 Item Part Description Number 1 Input shaft 2 Selector fork third/fourth gear 3 Selector fork fifth/reverse gear With the “ three - shaft transmission", all the gears are in permanent mesh. In each gear the required transmission ratio is achieved by means of a pair of gears. When the reverse gear is selected, the direction of the output shaft is changed by an idler gear. The input and output shafts turn on taper roller bearings. All the gears, including reverse, are bevel - cut, synchronized and turn on needle roller bearings. 4 5 6 Item Part Description Number 4 Output shaft 5 Reverse gear idler 6 Counter shaft
