Drenagem e reabastecimento do fluido da transmissão

Automatic Transmission/Transaxle – Vehicles With: 307-01-8 307-01-8 6-Speed Automatic Transaxle - 6R80 GENERAL PROCEDURES Transmission Fluid Drain and Refill Special Tool(s) Rubber Tip Air Nozzle 100-D009 (D93L-7000-A) ST2467-A Fluid Transporter/Evacuator/Injector 307-D465 ST2715-A Adapter, Fluid Level and Fill Plug 307-437 E129427 Vacuum Pump Kit 416-D002 (D95L-7559-A) Integrated Diagnostic System (IDS) Vehicle Communication Module, with appropriate ST1269-A adapters or equivalent diagnostic tool Materials Name Specification Transmission Fluid 0(5&21Š9 Drain 1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to Section 100-02. 2. NOTE: Some transmission fluid leakage may occur when removing the transmission fluid fill plug. Remove the transmission fluid fill plug fluid level indicator assembly located on the passenger side front portion of the transmission case. Removal of the transmission fluid fill plug will relieve any vacuum that might have built up in the transmission. This will aid in allowing the transmission fluid pan to be easily removed when the bolts are removed. E128906 3. Remove the transmission fluid pan and allow the transmission fluid to drain. E128907 4. NOTE: The transmission fluid pan gasket can be reused if not damaged. Install a new transmission fluid pan gasket, if required. E129417
