303-01C-32
Engine – 3.2L Duratorq-TDCi (148kW/200PS) - Puma
303-01C-32
REMOVAL AND INSTALLATION
6. Torque: 48 Nm
x3
E134532
7. Refer to: Lifting (100-02 Jacking and Lifting,
Description and Operation).
8. Torque: 30
Nm
x4
E130132
9. NOTE: Remove front RH side wheel only.
Refer to: Wheel and Tire (204-04 Wheels and
Tires, Removal and Installation).
10.
x8
E132537
11.
CAUTION: Cap the power steering line
to prevent fluid loss or dirt ingress.
Torque: 7
Nm
3
2
1
E133691
12.
x4
E133940
