Engine – 3.2L Duratorq-TDCi (148kW/200PS) - Puma
303-01C-31
303-01C-31
REMOVAL AND INSTALLATION
Timing Cover(21 146 0)
Special Tool(s)
303-428
Separator, Oil Pan
21179
303-682
Aligner, Engine Front Cover
303682
Materials
Name
Specification
Silicone Sealant LB
WSE-M4G323-A4 /
2U7J-M4G323-AA
Removal
NOTE: Removal steps in this procedure may
contain installation details.
1. Refer to: Battery Disconnect and Connect
(414-01 Battery, Mounting and Cables,
General Procedures).
2. Refer to: Cooling Fan Motor and Shroud (303-03
Engine Cooling - 3.2L Duratorq-TDCi
(148kW/200PS) - Puma, Removal and
Installation).
3. Refer to: Generator - 3.2L Duratorq-TDCi
(148kW/200PS) - Puma (414-02 Generator
and Regulator, Removal and Installation).
4.
1.
Torque: 35 Nm
2. Torque: 35 Nm
x2
2
x2
1
E134536
5.
1.
Torque: 48 Nm
2. Torque: 23 Nm
2
x2
1
E131304
