Motor

Engine – 2.2L Duratorq-TDCi (88kW/120PS) - Puma/2.2L Duratorq-TDCi (96kW/130PS) 303-01B-98 303-01B-98 - Puma/2.2L Duratorq-TDCi (110kW/150PS) - Puma ASSEMBLY 5. NOTE: Make sure that these components are installed to the noted removal position. Material: Engine Oil - 5W-30 (WSS-M2C913-C) engine oil E85147 6. NOTE: Make sure that these components are installed to the noted removal position. NOTE: Install all the bolts finger tight before final tightening. Torque: ‡ Stage 1: 25 Nm ‡ Stage 2: 60 Nm ‡ Stage 3: 90° E73644 7. E87419 8. NOTE: Only tighten the bolts finger tight at this stage. E138703 9. The ladder frame and the cylinder block must be aligned so that the side clearance does not exceed 0.05 mm overlap to 0.05 mm gap. Special Tool(s): 303-432 303-432 E76169
