Engine – 2.2L Duratorq-TDCi (88kW/120PS) - Puma/2.2L Duratorq-TDCi (96kW/130PS) 303-01B-97 303-01B-97 - Puma/2.2L Duratorq-TDCi (110kW/150PS) - Puma ASSEMBLY 1. NOTE: Make sure that these components are installed to the noted removal position. Material: Engine Oil - 5W-30 (WSS-M2C913-C) engine oil Torque: 10 Nm 3 1 x4 x4 2 E139686 2. NOTE: Make sure that these components are installed to the noted removal position. Material: Engine Oil - 5W-30 (WSS-M2C913-C) engine oil E85103 3. NOTE: Make sure that these components are installed to the noted removal position. NOTE: Install all the bolts finger tight before final tightening. Torque: ‡ Stage 1: 15 Nm ‡ Stage 2: 20 Nm ‡ Stage 3: 35 Nm ‡ Stage 4: 80 Nm ‡ Stage 5: 90° 5 3 1 7 10 4 2 6 8 E73645 4. General Equipment: Piston Ring Compressor Material: Engine Oil - 5W-30 (WSS-M2C913-C) engine oil x4 x4 E87405
