Pastilhas de freio

Front Disc Brake 206-03-3 206-03-3 REMOVAL AND INSTALLATION Rotate the brake caliper upwards E125508 5. CAUTION: When the brake caliper piston is retracted into the piston housing, brake fluid will be displaced into the brake fluid reservoir. NOTE: Make sure the brake pad contact points are clean and free from contamination. NOTE: Remove the adhesive foil from the rear of the brake pad. Special Tool(s): 206-005 206-005 E125509 Installation 1. CAUTIONS: Make sure that the mating faces are clean and free of foreign material and that no grease is applied to the brake pad guides. Do not allow grease, oil, brake fluid or other contaminants to contact the pad lining material. Do not install contaminated pads. Protect the piston and boots when pushing the caliper piston into the caliper piston bores. 2. To install, reverse the removal procedure. 3. CAUTION: The fluid level must remain between the MAX and MIN marks. NOTE: Depress the brake pedal, check the brake fluid level in the brake fluid reservoir and top up as necessary with brake fluid. Material: Brake Fluid - Super DOT4 (WSS-M6C57-A2) brake fluid E125844
