Mascaramento do farol

417-01- Exterior Lighting 417-01- GENERAL PROCEDURES 36. 1. Upper alignment edge of the headlamp lens. 2. Inner alignment edge of the headlamp lens. 3. Alignment aid. 4. Template. 1 2 3 4 E137474 All vehicles 37. CAUTION: Take extra care not to scratch the headlamp lens. Copy the outline of the template with a white board marker onto the headlamp lens. 38.Remove the template. 39.Copy the outline of the template on to the black adhesive tape. 40.Cut out the shape of the template from the black adhesive tape. 41.Use the pre-marked outline of the template drawn on the head lamp lens as the final position of the template, and stick template into this position. 42.Repeat steps 16 to 20 for the other head lamp. 43.Template for LHD vehicles, left-hand headlamp. 44. 1. Inner alignment edge of the headlamp lens. 2. Upper alignment edge of the headlamp lens. 3. Alignment aid. 4. Template. 2 1 3 4 [ E137478 45.Template for LHD vehicles, right-hand headlamp. 46. 1. Upper alignment edge of the headlamp lens. 2. Inner alignment edge of the headlamp lens. 3. Alignment aid. 4. Template. 1 2 3 4 [ E137477 47.Template for RHD vehicles, left-hand headlamp.
