Braço inferior (bandeja)

Front Suspension 204-01-17 204-01-17 REMOVAL AND INSTALLATION Lower Arm(14 706 0; 14 707 0; 14 709 0) General Equipment Two Leg Puller Removal CAUTION: Suspension fasteners are critical parts because they affect performance of vital components and systems and their failure can result in major service expense. A new part with the same part number or an equivalent part must be installed, if installation is necessary. Do not use a part of lesser quality or substitute design. Torque values must be used as specified during reassembly to make sure of correct retention of these parts. NOTE: Removal steps in this procedure may contain installation details. 1. Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation). Refer to: Wheel and Tire (204-04 Wheels and Tires, Removal and Installation). 2. 1. Torque: 85 Nm 2. Torque: 57 Nm 3. Torque: 67 Nm 2 1 x2 3 E125986 3. CAUTIONS: Do not damage the ball joint boot while installing the special tool. Do not use a hammer to separate the ball joint from the wheel knuckle or damage to the wheel knuckle can result. Make sure that the wheel knuckle is correctly secured. General Equipment: Two Leg Puller 49-T028-3A0 E125988 Installation CAUTION: Before tightening any suspension bushing fasteners, use a suitable jack to raise the suspension. 1. To install, reverse the removal procedure.
