100-00-3 General Information 100-00-3 DESCRIPTION AND OPERATION Position 1 2 3 4 and 5 Some circuit codes also have a suffix. Suffices are used when parts of a circuit are separated with a connector. Position 1: Potential Code G S H C V L R D Z Position 2: System Code A B C D E H L M P R Y Description Electrical potential System Sub-system Function Description GND (ground) Standard voltage Higher than standard voltage Changing or switched Variable signal Lower than standard voltage Return or reference Drain wire Any of the above with a temporary function Description Special vehicle Circuit protection Chassis Electrical distribution Engine and transmission Heating Lighting Multimedia (Information and entertainment) Power convenience Supplemental restraints Hybrid electric powertrain 2012.0 Ranger 100-00-3
