Painel traseiro – Cabine dupla

501-30-6 Rear End Sheet Metal Repairs 501-30-6 REMOVAL AND INSTALLATION E139805 Installation 1. NOTE: Before resistance spot welding of body panels with a total panel thickness of 3 mm and greater, the manufacturer's welding equipment instructions and sub-section 501-25 must be followed. Refer to: Tools and Equipment for Body Repairs (501-25 Body Repairs - General Information, Description and Operation). 2. NOTE: Sealer or adhesive must not be applied in welding zones. Areas which were bonded or sealed needs to be thoroughly sealed afterwards. Refer to: Sealer, Underbody Protection Material and Adhesives (501-25 Body Repairs - General Information, Description and Operation). 3. ‡ Resistance spot weld - Panel thickness 3 mm and greater.
