Manual Transmission/Transaxle – Vehicles With: 5-Speed 308-03A-27 308-03A-27 Manual Transmission - MT75 DISASSEMBLY Special Tool(s) Mounting Bracket for 303-435 308-114 (16-045) 16045 Mounting Brackets for 308-114 308-114-01 (16-045-01) 30811401 Remover, Slider 308-652 E77040 Disassembly All vehicles NOTE: All the bearings are paired and must not be mixed. 1. Remove the external gearshift control cover. E91969 2. Detach the external gearshift control assembly. 1. Remove the nut. 2. Remove the bolts. 2 1 2 E73383 3. Using the special tool, detach the shifter shaft connector. ‡ Remove the external gearshift control assembly. 308-652 308-652 E92145 Vehicles with tachograph 4. Remove the tachograph sensor. ELE0019852 All vehicles 5. Drain the transmission. ‡ Remove the drain plug.
