Especificações

Engine – 3.2L Duratorq-TDCi (148kW/200PS) - Puma 303-01C-4 303-01C-4 SPECIFICATIONS Description – upper compression ring – lower compression ring – oil control ring Piston ring gap position: The piston ring end gaps must be distributed evenly around the circumference of the piston. This also applies to the oil control ring elements. Align the piston ring end gaps at 120 degrees to each other. Crankshaft Dimensions Description Main bearing journal end float Main bearing journals 1 to 5 diameter Main bearing journal 6 diameter Connecting rod bearing journal diameter Connecting Rod Dimensions Description Large end bore diameter Small end bore diameter Connecting rod bearing shell inner diameter – bearings installed Connecting rod bearing radial clearance Connecting rod bearing axial clearance Piston Pin Dimensions Description Piston pin length Piston pin diameter Piston pin slide clearance Camshaft Dimensions Description Camshaft end float Camshaft bearing journal diameter Camshaft bearing clearance – radial measurement Valve Dimensions Description Valve stem to valve guide clearance – intake valve Valve stem to valve guide clearance – exhaust valve Cylinder Head Dimensions Description Maximum distortion – measured longitudinally and diagonally mm 0.25 - 0.40 0.50 - 0.75 0.25 - 0.50 mm 0.090 - 0.305 64.950 - 64.970 69.950 - 69.970 52.980 - 53.000 mm 55.996 - 56.016 32.010 - 32.018 53.016 - 53.046 0.026 - 0.084 0.100 - 0.320 mm 73.95 31.998 - 32.002 0.008 - 0.018 mm 0.014 - 0.200 26.440 - 26.465 0.04 - 0.09 mm 0.0625 - 0.0275 0.0725 - 0.0375 mm 0.10
