Engine – 2.2L Duratorq-TDCi (88kW/120PS) - Puma/2.2L Duratorq-TDCi (96kW/130PS)
303-01B-30
303-01B-30
- Puma/2.2L Duratorq-TDCi (110kW/150PS) - Puma
REMOVAL AND INSTALLATION
6. Torque: 48 Nm
x3
E134532
7. Refer to: Lifting (100-02 Jacking and Lifting,
Description and Operation).
8. Torque: 30 Nm
x4
E130132
9. NOTE: Remove front RH wheel only.
Refer to: Wheel and Tire (204-04 Wheels and
Tires, Removal and Installation).
10.
x8
E132537
11.
CAUTION: Cap the power steering line
to prevent fluid loss or dirt ingress.
Torque: 7 Nm
3
2
1
E133691
12.
x4
E133940
