303-01A-77
Engine – 2.5L Duratec-HE (122kW/165PS) - MI4
303-01A-77
DISASSEMBLY
9.
E66316
10.Special Tool(s): 100-010
General Equipment: 2 mm Punch
2
100-010
1
3
E66041
11.
x2
E134744
12.Remove the RH timing chain guide.
A0032596
13.Remove the timing chain.
x2
1
2
E134745
14.
CAUTION: Use an open-ended wrench
to hold the camshafts by the hexagon
to prevent the camshafts from turning.
