Conicidade do cilindro

Engine System - General Information 303-00-10 303-00-10 GENERAL PROCEDURES Cylinder Bore Taper 1. NOTE: The main bearing caps or lower crankcase must be in place and tightened to the specified torque; however, the bearing shells should not be installed. Measure the cylinder bore with an internal micrometer. ‡ Carry out the measurements in different directions and at different heights to determine if there is any out-of-roundness or tapering. ‡ If the measurement is out of the specified range, install a new block or hone out the cylinder block (if aplicable/allowed). m m A B C ELE0008659
