Steering Linkage 211-03-2 211-03-2 REMOVAL AND INSTALLATION Tie Rod(13 263 0) Special Tool(s) / General Equipment 204-169 Clamping Tool, Boot Retaining Clamp 14044 Flat Headed Screw Driver Vise Vise Jaw Protectors Materials Name Specification Silicone Grease ESE-M1C171-A / 2S5J- M1C171-AA Removal NOTE: Removal steps in this procedure may contain installation details. 1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures). Refer to: Steering System Health and Safety Precautions (100-00 General Information, Description and Operation). 2. Refer to: Steering Gear (211-02 Power Steering, Removal and Installation). 3. On both sides. E130478 4. NOTE: Note the position of component before removal. On both sides. General Equipment: Flat Headed Screw Driver E137459 5. NOTE: Note the position of component before removal. On both sides. Special Tool(s): 204-169 204-169 E130475 6. CAUTION: Use vise jaw protectors. Rotate the steering gear pinion to expose the steering rack. General Equipment: Vise General Equipment: Vise Jaw Protectors TIE0004984
