413-13-4
Parking Aid
413-13-4
DESCRIPTION AND OPERATION
Wagon
2
1
8
7
E92008
Item
Description
1
Parking aid switch (with light emitting
diode (LED)).
2
Front parking aid speaker.
3
Rear parking aid speaker.
4
Rear inner parking aid sensor and holder.
4
3
5
6
Item
Description
5
Rear outer parking aid sensor and holder.
6
Parking aid module.
7
Front outer parking aid sensor and holder.
8
Front inner parking aid sensor and holder.
