413-01-11
Instrument Cluster
413-01-11
REMOVAL AND INSTALLATION
7. Torque: 2 Nm
x3
E126843
Installation
1. To install, reverse the removal procedure.
2. NOTE: This step is only necessary when
installing a new component.
Upload the instrument cluster configuration
information using the programmable modules
installation routine.
General Equipment: Ford Diagnostic Equipment
3. NOTE: This step is only necessary when
installing a new component.
Configure the PATS system using the
programmable modules installation routine.
