100-00-6 General Information 100-00-6 DESCRIPTION AND OPERATION System Code Sub-system Code P W R 1 R 2 R B R D R H R P R T R W Y A Y B Y D Y T Wire Insulation Specification (Temperature) Code WA WK WE Connector Code - Component, GND and Splice Code Position 1 2 3 4 5 6 7 Connector locations are shown graphically and displayed by selecting the appropriate link on the wiring diagram. Description Power windows RCM (restraints control module), air bag module, side air curtain module Impact sensor, PAD (passenger air bag deactiva- tion) switch Blind spot monitoring Heated windshield, rear window, mirrors, washer jets Horn Pedestrian protection Anti-theft Windshield wipers and washers, rear window wiper and washer, headlamp washers DC (direct current)/AC (alternating current) inverter Traction battery DC/AC converter Hybrid power split transmission/transaxle Temperature 100°C 125°C 150°C Description C = connector, G = GNDand S = splice Connector location System Sub-system Function Function Suffix (only used if multiple connectors exist) 2012.0 Ranger 100-00-6
