Acabamento superior da coluna C

C-Pillar Upper Trim Panel

Carroceria · página 44 de 566 · 501-05-5 · parte 1 de 2

Página 44 do Manual de Carroceria: Acabamento superior da coluna C

Explicar no Gemini Ampliar imagem Traduzir texto

Texto da página

Link desta página: https://ranger.mbrace.com.br/carroceria/44
Imagem: https://ranger.mbrace.com.br/img/carroceria/44.webp

501-05-5 Interior Trim and Ornamentation 501-05-5 REMOVAL AND INSTALLATION C-Pillar Upper Trim Panel Removal NOTE: Removal steps in this procedure may contain installation details. 1. Refer to: Rear Safety Belt Retractor (501-20 Safety Belt System, Removal and Installation). 2. Refer to: C-Pillar Lower Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation). Single cab 3. x8 E125839 Stretch cab 4. x6 E126093 5. x6 E126095
