501-27-2 Front End Sheet Metal Repairs 501-27-2 REMOVAL AND INSTALLATION Front Fender Removal NOTE: Removal steps in this procedure may contain installation details. 1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures). 2. Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation). 3. Refer to: Headlamp Assembly (417-01 Exterior Lighting, Removal and Installation). 4. E128828 5. E128788 6. Torque: 9 Nm E133768
