Body Repairs - Vehicle Specific Information
501-26-5
and Tolerance Checks
501-26-5
DESCRIPTION AND OPERATION
Air Bag and Safety Belt Pretensioner Supplemental Restraint System (SRS) for single cab
14
13
12
11
3
4
7
E128765
Item
Description
1
Instrument cluster with air bag indicator
light and safety belt warning light.
2
Driver air bag
3
Curtain air bag
4
Side impact sensor
5
Front safety belt retractor
6
Side air bag
2
1
3
4
5
6
7
10
8
5
Item
Description
7
Front safety belt buckle
8
Restraints control module
Front center safety belt retractor
10
Front center safety belt buckle
11
Passenger airbag deactivation switch
12
Passenger air bag
