Limpadores e lavadores

501-16-3 Wipers and Washers 501-16-3 DESCRIPTION AND OPERATION When the intermittent wipe mode is switched on the windshield wipers operate at normal speed with the following wiper delays: ‡ Wiper delay 1: 1 second ‡ Wiper delay 2: 3.5 seconds ‡ Wiper delay 3: 6 seconds ‡ Wiper delay 4: 9,5 seconds ‡ Wiper delay 5: 15.5 seconds ‡ Wiper delay 6: 22 seconds NOTE: In the event of a failure, or if the control resistor is not connected the default time for the wiper delay is 8 seconds. When the windshield washer switch is operated washer fluid is sprayed onto the windshield. After a short delay designed to protect the wiper blades the wipers perform 2 or 3 wipes at low speed. If when the windshield washer switch is activated the windshield wipers are switched off, then a single wipe is performed 4 seconds after the wipers have returned to the home position after performing the 2 or 3 wipes. If when the windshield washer switch is activated the wipers are in intermittent mode, and if the selected wiper delay time is longer than 6 seconds, then a single wipe is performed 6 seconds after the wipers have returned to the home position after performing the 2 or 3 wipes. If the selected delay time is less than 6 seconds then no post wipe is required. The post wipe function on the windshield ensures that any water remaining on the windshield after washing is wiped away. It is only required if the wipers are switched off or they are set to intermittent mode.
