Instrument Panel and Console
501-12-13
501-12-13
REMOVAL AND INSTALLATION
12.
1.
Torque: 3
Nm
2. Torque: 2 Nm
x2
2
x2
1
E127964
13.Torque: 10
Nm
x2
x2
E127965
14.Refer to: Ignition Switch (211-05 Steering
Column Switches, Removal and Installation).
15.Refer to: Steering Wheel (211-04 Steering
Column, Removal and Installation).
16.
1
2
2
3
E127835
17.Torque: 7
Nm
