Instrument Panel and Console
501-12-5
501-12-5
REMOVAL AND INSTALLATION
12.
x2
x2
E129568
13.Torque: 10 Nm
x4
E139787
14.Refer to: Ignition Switch (211-05 Steering
Column Switches, Removal and Installation).
15.Refer to: Steering Wheel (211-04 Steering
Column, Removal and Installation).
16.
1
2
2
3
E127835
17.
1.
Torque: 7 Nm
