501-11-22 Glass, Frames and Mechanisms 501-11-22 REMOVAL AND INSTALLATION Rear Window Glass General Equipment Adhesive Tape Direct Glazing Removal/Replacement Equipment Knife Removal 1. Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation). 2. Refer to: C-Pillar Upper Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation). 3. Refer to: Headliner (501-05 Interior Trim and Ornamentation, Removal and Installation). 4. Refer to: Rear Seat (501-10 Seating, Removal and Installation). 5. ‡ Material: Windshield Adhesive Kit (WSS-M11P57-A5) adhesive ‡ Remove the polyurethane (PU) adhesive cap and heat the 2K-PU adhesive for a minimum of 30 minutes. General Equipment: Direct Glazing Removal/Replacement Equipment ‡ Repairs under warranty: Material: Windscreen Adhesive Kit - 1 Component (WSK-M11P57-A3 / 7U7J-T03863-AA) adhesive TIE0022871 Materials Name Specification Windscreen Adhesive WSK-M11P57-A3 / Kit - 1 Component 7U7J-T03863-AA Windshield Adhesive Kit WSS-M11P57-A5 6. E129042 7. NOTE: Vehicles with heated windsheild only. E129011 8. Use a suitable awl to thread the cutting wire. General Equipment: Direct Glazing Removal/Replacement Equipment
