501-11-8 Glass, Frames and Mechanisms 501-11-8 REMOVAL AND INSTALLATION Use a suitable awl to thread the cutting wire. General Equipment: Direct Glazing Removal/Replacement Equipment E127692 12. CAUTION: If the original window glass is to be installed, take care not to damage the electrical connectors and the weatherstrip (if equipped). Use a suitable brace to prevent trim damages. General Equipment: Direct Glazing Removal/Replacement Equipment x2 E127693 13. E127690 Installation 1. NOTE: Minimum 1 mm bead thickness. ‡ General Equipment: Knife ‡ NOTE: Make sure that the mating faces are clean and free of foreign material. ‡ NOTE: Touching the adhesive surface will impair rebonding. ‡ Prepare the windshield glass, windshield glass flange and trimmed PU adhesive in accordance with the instructions supplied with the glass adhesive kit. 1 2 E114059 2. Apply the activator/primer in accordance with the instructions supplied with the glass adhesive kit.
