Engine – 2.2L Duratorq-TDCi (88kW/120PS) - Puma/2.2L Duratorq-TDCi (96kW/130PS)
303-01B-14
303-01B-14
- Puma/2.2L Duratorq-TDCi (110kW/150PS) - Puma
REMOVAL AND INSTALLATION
7.
x2
x3
x3
x2
x2
E95464
8.
x10
E75617
9.
CAUTION: Remove the camshaft carrier
bolts in the sequence shown.
1
7
15
19
21
23
13
5
3
17
11
9
12
10
4
18
2
8
16
20
22
24
14
6
E75958
Installation
NOTE: Clean the mating faces of the camshaft
carrier and the cylinder head.
1.
Bolts 1 to 22
Torque: 23 Nm
Bolts 23 to 25
Torque: 10
Nm
1
7
15
19
21
23
13
5
3
17
11
9
12
10
4
18
2
8
16
20
22
24
14
6
E75958
2. Torque:
Stage 1: 10
Nm
Stage 2: 30°
x10
E75617
3. Install the Special Tool(s): 303-1562
303-1562
E138698
