Engine – 2.2L Duratorq-TDCi (88kW/120PS) - Puma/2.2L Duratorq-TDCi (96kW/130PS)
303-01B-11
303-01B-11
- Puma/2.2L Duratorq-TDCi (110kW/150PS) - Puma
DESCRIPTION AND OPERATION
3
4
5
1
2
E131390
1.
Item
Description
1
Oil sump
2
Turbocharger
3
vacuum pump
4
Valve cover
6
7
8
Item
Description
5
Fuel injection rail
6
Intake manifold
7
Oil cooler
8
Coolant pump
Fuel pump
