Lavagem do sistema de direção hidráulica

Steering System - General Information 211-00-3 211-00-3 GENERAL PROCEDURES Power Steering System Flushing Activation CAUTION: Do not mix fluid types. Any mixture or any unapproved fluid may lead to seal deterioration and leaks. A leak may ultimately cause loss of fluid, which may result in a loss of power steering assist. 1. E130730 2. Using a suitable suction device, remove the power steering fluid from the reservoir. 3. Remove the clamp from the hose and allow the remaining fluid to drain out of the reservoir. E130731 4. Plug the power steering fluid reservoir inlet port. E130732 5. Attach an extension hose to the return hose. 6. NOTE: Do not reuse the power steering fluid that has been flushed from the power steering system. Place the open end of the extension hose into a suitable container. 7. If equipped with Hydro-Boost®, apply the brake pedal 4 times. 8. NOTE: Do not overfill the reservoir. Fill the reservoir as needed with the specified fluid. 9. CAUTION: Do not allow the power steering pump to run completely dry of power steering fluid. Damage to the power steering pump may occur. Start the engine and let it idle, simultaneously turn the steering wheel to lock and then immediately turn the ignition switch to the OFF position. 10. CAUTION: Avoid turning the steering wheel without the engine running as this may cause air to be pulled into the steering gear. NOTE: Do not overfill the reservoir. Fill the reservoir as needed with the specified fluid.
