Painel – RHD 4WD/RHD RWD
Instrument Panel – RHD 4WD/RHD RWD
Texto da página
Link desta página: https://ranger.mbrace.com.br/oficina/1398
Imagem: https://ranger.mbrace.com.br/img/oficina/1398.webp
501-12-11
Instrument Panel and Console
501-12-11
REMOVAL AND INSTALLATION
Vehicles with driver lower air bag
5. Refer to: Driver Lower Air Bag Module (501-20
Supplemental Restraint System, Removal and
Installation).
Vehicles without driver lower air bag
6.
x8
E127966
7. Torque: 2 Nm
x2
E127842
All vehicles
8. Refer to: Glove Compartment (501-12
Instrument Panel and Console, Removal and
Installation).
9. Refer to: Cowl Side Trim Panel (501-05 Interior
Trim and Ornamentation, Removal and
Installation).
10.
E131193
11.
x3
E127963
