417-01-32
Rear Lamp Assembly LH (G1404501)
Rear Lamp Assembly RH (G1404502)
Reversing Lamp Switch (G1404503)
PIN 1 => CET47A BU 0.5 4TBD + CET47 BU 0.5 4TBD
PIN 2 => GD122Z BK 0.5 4TBD
1
CET47
BU
4TBD
0.5
2
GD122N
BK
4TBD
0.5
+
GD122Z
BK
4TBD
0.5
XR3T-14A464-AA
C1ET47
TO REVERSE LAMP SWITCH
HARNESS 14K039
Side Turn Signal Lamp LH (G1404504)
1
CLS55H
GN-BU
3TBD
0.5
2
GD121AA
BK-YE
3TBD
0.5
MNNL-WD-2F
C1LS21
TO FRONT TURN LAMP LH
HARNESS 14290
