Painel de instrumentos (G1404379)
Instrument Cluster (G1404379)
Texto da página
Link desta página: https://ranger.mbrace.com.br/eletrico/180
Imagem: https://ranger.mbrace.com.br/img/eletrico/180.webp
413-01-6
Instrument Cluster (G1404379)
PIN 1 => VDB14F VT-GY 0.35 2TAD + VDB14E VT-GY 0.35 2TAD
PIN 2 => VDB13F BU-GY 0.35 2TAD + VDB13E BU-GY 0.35 2TAD
CDC35F
BU-WH
2TAD
0.35
9
CR201B
GN-BU
2TAE
0.35
8
CRT03
WH-VT
2TAD
0.35
7
6
5
VDB06V
GY-OG
2TAD
0.35
+
VDB06T
GY-OG
2TAD
0.35
4
VDB07V
VT-OG
2TAD
0.35
+
VDB07T
VT-OG
2TAD
0.35
3
VDB13E
BU-GY
2TAD
0.35
+
VDB13F
BU-GY
2TAD
0.35
2
VDB14E
VT-GY
2TAD
0.35
+
VDB14F
VT-GY
2TAD
0.35
1
3F2T-14488-BB
C2MC01
TO INSTRUMENT PANEL CLUSTER
HARNESS 14401
2012.0 Ranger
18
CBP85A
YE 2TAD
0.35
17
CBP69D
WH-VT
2TAD
0.35
+ CBP69A
WH-VT
2TAD
0.35
16
CDC41A
WH-BN
2TAD
0.35
15
CMC37
VT-GN
2TAD
0.35
14
VDB14E
VT-GY
2TAD
0.35
13
VDB13E
BU-GY
2TAD
0.35
12
11
GD215V
BK-GY
2TAD
0.35
10
